μOLED process
Product Highlights
- High PPI (> 5000ppi)
- For μOLED (OLEDoS) characteristic Design
- Digital Current Driving (PWM driving)
- Independent R/G/B Gamma Control
- Low-Power Consumption Design
- De-Mura Compensation
- Over-Temperature Protection
- High-Speed MIPI (with DSC) Interface
- Low-Power QSPI Interface
- Both 8" and 12" HV Process
Product Information
| Off-the-Shelf (OTS) products | ||||
|---|---|---|---|---|
| Product Name | Process | Display Size | Resolution | Interface |
| UD65640 | 8" / 70nm | 0.25" | 640RGBx480 (Color) 640x480 (Mono) | MIPI / QSPI / RGB |
| UD65080 | 12" / 55nm | 0.55" | 1920RGBx1080 (Color) | MIPI |
| Customized Product |
|---|
| Accepting Design Commissions (NRE) |
